Oil Country Tubular Goods

API Tubing

Product: Tubing Pipe, Oil Tubing, API Tubing Well Tubing, Tubing
Application:  Used for extracing Oil or Gas from Wells
Size: OD: 48.26mm-114.3mm
 WT: 3.18-16mm
 LENGTH: R1, R2, R3
Pipe Standard:  API 5CT PSL1/PSL2  J55,K55,N80-1,N80-Q,
 API 5CT PSL1/PSL2  L80-1, L80-9Cr,L80-13Cr,C90, C95, P110, Q125
Thread: NUE, EUE, VAM, STC, LTC, BTC, XC, VAM TOP, NEW VAM,HYDRILL CS
Special Service Sweet Service, Sour Service, Anti-H2S, NACE MR0175/ISO15156
Accessories:  Pup Joint, Coupling, Drill Collar, Crossover etc.
قبل
بعدی

Description

Tolerance

Pipe TypesPipe Size (mm)Tolerances
Hot RolledOD≤159±1.0%
>159±1.20%
WT≤20±12.5%
>20±10.0%
Cold DrawnOD≤30±0.20mm
30-50±0.30mm
>50±0.8%
WT≤3+12%  -10%
>3±10%

Chemical Composition & Mechanical Properties

GradeChemical CompositionMechanical Properties
CMnSiCrMoNiSPTensile Strength(Mpa)Yield Strength(Mpa)Elongation(%)
100.07-0.140.35-0.650.17-0.37≤0.15–≤0.25≤0.035≤0.035330-490≥205≥24
200.17-0.240.35-0.650.17-0.37≤0.25–≤0.25≤0.035≤0.035410-550≥245≥21
12CrMo0.08-0.150.40-0.700.17-0.370.40-0.700.40-0.55≤0.30≤0.035≤0.035410-560≥205≥21
15CrMo0.12-0.180.40-0.700.17-0.370.80-1.100.40-0.55≤0.30≤0.035≤0.035440-640≥235≥21
1Cr2Mo≤0.150.30-0.600.50-1.002.15-2.850.40-0.65–≤0.035≤0.035≥390≥175≥22
1Cr5Mo≤0.15≤0.60≤0.604.00-6.000.45-0.60≤0.60≤0.035≤0.035≥390≥195≥22
